continuous polyurethane styrofoam eps foam production line

continuous polyurethane foam production line

continuous polyurethane styrofoam eps foam production line

This machine advantage:

1,High capacity : 45-60sec./cycle for easy EPS products, 70-100 seconds/cycle for big products.(open/close the mould,baiting,cooling)

2,save steam: this machine adopts allenbach big flow with low pressure, it can save 1/4 steam compare other factory.

3,high quality: moving parts use durable sleeve made in Japan, main components use word famous brand which can gurantte long service life.

4,multi-function:it can fit both big and small mold

2.Technical data of polyurethane styrofoam eps foam production line

Mould dimension mm 1200x1050 1400x1250 1750x1450 2000x1650
Max product dimension mm 1050x900x420 1250x1100x420 1600x1300x420 1850x1500x420
Stroke mm 150-1500 150-1500 150-1500 150-1500
Steam entry inch 3"(DN80) 4"(DN100) 4"(DN100) 4"(DN100)
Steam consumption KG/cycle 5-7 6-9 8-12 9-15
Steam pressure Mpa 0.5-0.7 0.5-0.7 0.5-0.7 0.5-0.7
Cooling water entry Inch 2.5"(DN65) 3"(DN80) 3"(DN80) 3"(DN80)
Cooling water consumption KG/cycle 45-130 50-150 55-180 90-220
Cooling water pressure Mpa 0.3-0.5 0.3-0.5 0.3-0.5 0.3-0.5
Compressed air entry Inch 1.5"(DN40) 2"(DN50) 2"(DN50) 2"(DN65)
Compressed air consumption M3/cycle 1.5 1.8 2 2.5
Compressed air pressure Mpa 0.5-0.7 0.5-0.7 0.5-0.7 0.5-0.7
Drainage Inch 5"(DN125) 6"(DN150) 6"(DN150) 6"(DN150)
Capacity 15kg/m3 Second 60-120 70-140 80-150 100-200
Connected load/power kw 9 12.5 16.5 16.5
Overall dimension(LxWxH) mm 4750x1750x3130 4750x1920x3250 4750x2030x3450 4750x2240x3680
weight KG 5000 5500 6000 7000

3. Feature polyurethane styrofoam eps foam production line

1.this EPS machine adopts PLC programmable controller and touch human-machine interface control, advanced foam moulding process,can produce a variety of products.

2.this EPS machine produced a variety of foam products, low moisture content, forming speed, low consumption, size and stability

3.this EPS shape moulding machine executable automatic, semi-automatic and manual operation started in the middle of 4 operation mode,equipped with safety protection devices, can enssure safe and reliable operation.

4.this EPS shape moulding machine uses programmable controllers, touch human-machine interface, executable computer production control management, high degree of automation, simple operation, easy maintenance, labor intensity at the end.

5.this EPS machine adopts the international advanced electrical and hydraulic integration,improve the speed of molding products, a significant reduction in energy consumption and reduce enviromental pollution.

6.this machine uses a variety of heating process, a variety of feeding methods and cooling.

7.this EPS machine vacuum system to accelerate the rate of product effectiveness, reduce cooling time, product moisture content is low.

8.this EPS machine uses the control instruments, eletrical, pneumatic components, valves and other supporting both dometic and foreign high quality brand name products.

9.ML-1400 type EPS foam box shape moulding machine can load 1000-1400mm mold, ML-1750 mold can load 1400-1750mm mold.

10.the aircraft can choose mechanical or hydraulic release models.

-Our services---

1. Value clients, guarantee equipment quality and answer clients’ questions anytime and anywhere.
2. Customizing machines according to clients' inquiry , such as different design, different brand parts, different colors, more function,etc.
3. Engineers go to clients' factory in time for installation , training and trial production .
4. 1 year free warranty, Lifetime technical service support, some spare parts will be send to our customer free of charge.

Quick Details

Processing Type: Foaming Machine
Condition: New
Product Type: Foam Net
Place of Origin: China (Mainland)
Brand Name: EMM
Voltage: 380V/50HZ or customized
Power(W): 9kw-12.5kw
Weight: 5500KG
Certification: CE
Warranty: 12 months
After-sales Service Provided: Engineers available to service machinery overseas
Application:EPS packaging box. icf panel,decoration cornice, fish box, fruit box
Automatic: Full automatic EPS polystyrene foam machine
Material: Steel structure, stainless steel eps foam machine
Special: foam machinery, plastic vacuum forming machines
Raw material: EPS, expandable Polystyrene, Styrofoam, Thermocol
Certificate: CE ISO9001
Control System: PLC+Touch Screen
Machine Type:continuous polyurethane styrofoam eps foam production line
HS code: 84778000 foaming machine
eps machine: EMM continuous polyurethane
