PU safety shoe making machine DIP shoe banana type production line

pu shoe production line

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Warranty: life-time
Weight: 2800kgs
Voltage: 220V or 380V
Brand Name: EMM
Certification: CE
Dimension(L*W*H): 8000*9000*2350mm
Power(W): 34KW
Model Number: LZ-XC
Production Capacity: 500-10000 pairs/day
Condition: New
Feature 1: robotic injection, banana type
feature 2: mold open and close automatic
application: pu soles, safety shoes, slipper, sandals and other pu shoes
Raw material: polyurethane(=ISO+POLY)
required labor: 2~3 people

PU safety shoe making machine DIP shoe banana type production line

Product Application

this equipment is used to produce polyurethane insoles, outsoles, high heels, leather shoes, casual shoes, safety shoes, travel shoes,slippers, sandals, flip flops and other all kinds of polyurethane shoes.

Product Component

this equipment includes one three components low pressure PU foam machine and one automatic banana-type production line. According to the client's production capacity, the production line has 24, 36, 60, 80,100,120 or other mold stations for choose.

Three-components inject machine
Item No.
Type of applicable foam
Sole,insole, walking shoe, etc.
Flux of inject
30g-100g/S (Attention:the flux could be configured)
the mix proportion
Process of injecting
Manual or automatic inject by PLC programmed for choose
Wide:2.1M; High:2.35M; Long:3.5M
Weight of the machine
Pneumatic molds Production line
Pneumatic mold station
24,36,60,80,100,120 mold station for choose
Mold station
Open and close automatically
Material for work station
3mm, iron plate
Mold heating way
Water recycling system
Water heating box
150L,304 stainless steel

Why choose it:

1. most of the components are imported, like the metering pump and electrical components, greatly enhancing equipment running reliability and service life;

2. the moulds can be opened and closed automatically by the pneumatic system which can Save the labor cost and around 2~4 people are required for the production only.

3. the molds are heated by circulating Water heating system, iT can Save 3/2 electricity compared with the traditional manual machine, it also makes the temperature of the molds stabler.

4. the injection can be or can not be robotic control, which is customized for the client.
