flexible polyurethane foam neck rest pillow ring production line machine

neck rest pillow ring production line machine

Quick Details

Condition: New
Application: pu memory pillow
Plastic Processed: PU
Screw Design: memory foam pillow review
Automatic Grade: customizable
Place of Origin: China (Mainland)
Brand Name: EMM polyurethane
Voltage: 380V 50HZ 3Phase(Customized)
Power(W): customizable
Dimension(L*W*H): customizable
Certification: CE ISO
After-sales Service Provided:Engineers available to service machinery overseas
Name: ring production line
Raw material: PU
Processing Type: Mixing head inject raw material
Product: pu memory pillow
Usage: Production of polyurethane memory pillow
Product Type: production line
Other name: memory foam cooling pillow
Color: Customizable
Type: gel memory foam
Warranty: 1 Year

Flexible Polyurethane foam neck rest pillow ring production line machine

Pillow production line can be divided into three parts: low pressure foam machine, pillow production line, pillow mold.

Low pressure foam machine technical Parameter:

Injection output: 2-1000g/s
Material tank volume: 30L-120L
Mixing ratio range: 100:28~48
Mixing head: 2800-5000rpm, forced dynamic mixing
Compressed air needed: dry, oil free, P:0.6-0.8MPa Q:600NL/min(customer-owned)
Nitrogen requirement: P:0.05MPa Q:600NL/min(customer-owned)
Temperature control system: heat:2×3KW
Input power: three-phase five-wire 380V 50HZ Other power customizable
Rated power:8KW-12KW
Color( customizable): White/Red/Blue
Weight: 600Kg-1200Kg
Dimension: 4100(L)*1250(W)*2300(H)mm
Equipment Overview:
PU foaming machines have wide application in the market, which have features of economy and convenient operation and maintenance,etc. The machines can be customized according to customers' requirement for various output and mixing ratio.
