high pressure polyurethane floral foam machine

high continuous pressure machine

1.Electrical heating reaction vessel

Product features:

1. Principle: the principle of electrical heating the reaction kettle is insert electric heater in the jacketed heat conduction oil,

using thermal oil as medium is introduced into the wall of a kettle, make the material inside the kettle is heated response.

Reaction pot consists of pot, stainless steel tube body, jacket, mixer, shaft sealing device and bearing, shaft sealing device

is divided into packing seal and mechanical seal

2. Characteristics:

1) can be according to customer request custom anchor type wheel, impeller, pan, pusher, or box type mixing form, as well as

the mixing of different combinations.

2) can be customized according to customer requirements of various kinds of heat exchanger, including jacket, coil,

electric heating, steam heating, heat conduction oil heating

3) optional explosion-proof performance, sealing performance, positive pressure and negative pressure in various configurations

4) due to a large number of design, manufacture, sale of non-standard stirred tank, accumulated a wealth of industry experience, to customers' requirements

More understand the hole quantity, specifications or other requirements, can according to user requirements design,

processing production separately.

2.Two Component Floral Foaming Machine

Product Feature:

1. Main unit: Material injection by a precision needle valve, which is taper sealed, never worn, and never clogged; the mixing head

produces complete material stirring; precise metering (by a precision metering pump); single button operation for convenient

operation; switching to a different density or color at any time.

2. Control : Microcomputer PLC control; TIAN electrical components exclusively imported to achieve the goal for automatic,

accurate and reliable control can be imputed with more than 500 working position data; pressure, temperature and rotation rate

digital tracking and display and automatic control; abnormity or fault alarm devices. Import converter (PLC) can control eight

different product ratio.

3.Foaming mould

Product Feature:

Using automatic electrical heating temperature control system, make floral foam heated evenly, temperature is consistent.

And make floral foam forming rules, uniform density, hardly any waste generated.

4.Cutting machine and Printing machine

Product features: computer control, simple operation. Equipped with suction machine, greatly reduces the floral foam

powder pollution, make working environment more healthy.

into packing seal and mechanical seal.

e and reliable control can be imputed with more than 500 working position data; pressure,temperature

and rotation rate digital tracking and display and automatic control; abport converter

(PLC) can control eight different product ratio.

Equipment modelEMM-803
SourceTotal power 22KW,4*220V/60HZ
Suit foam typePhenol aldehyde flower mud
Injection flow1500g-2500g/S note: the size of flow can be set

Injection pressure

Mix ratio100-15;100-30
viscosity(22 )Resin 500-3000MPAS
viscosity(22°C)Acidic curing agent 500-2000MPAS
Feeding time0.01-99.9/S(accuracy 0.01S)
Injection materials Precision0.1/100
Injection procedure numberPLC program manual injection
Pneumatic work pressure0.6-0.8MPa
Floor spaceWide 5M   height 3.2M
Overall weight1.8t
Mixed casting headUse ball value type
PLC Programming Computer

Chinese show(Taiwan Delta)

can control 100 different mould (product)

pouring quantity at the same time, can

automatic cleaning machine

Heating systemCan automatic control temperature
3.5KW water cycle vacuum pump

and storage tank

A set
10P refrigeration unitA set


1.Can I get free samples?
YES. We would like to send several samples for your reference if you could afford freight.

2.What surface handing could you support ?

We can provide help buyer print logo on the foam and carton.

3.Do you accept customized order ?
YES. We can arrange opening the mould according to customers’ requirement.

4. What is the normal lead time ?
(1). For stock products, we will send goods to you within 12-24hours after we receive your payment.

(2). For surface handing products, the delivery time is within 7-10 work days after we receive your payment.
(3). For products we never manufactured , we could open the mould if needed.

5. What is your selection of shipping method ?

(1). For small trial order, international express, just as UPS, FedEx, TNT, EMS, DHL is suitable.

(2). For large order, we can arrange shipment by sea or air according to your requirement.

6.How do you control the quality ?

We do 3 times leakage test before packing.

7.If any defective floral foam, how do you deal with ?

We have 1:1 replacement for the defective floral foam.

8.Which trade terms do you prefer?

We can accept FOB, C&F, CIF,etc.

9.What's your Payment terms?
T /T, Western Union, etc.

Quick Details

Processing Type: Foaming Machine
Condition: New
Product Type: Foam Net
Place of Origin: , China (Mainland)
Brand Name: EMM
Voltage: customized
Power(W): customized
Dimension(L*W*H): customized
Weight: customized
Certification: CE
Warranty: one year
After-sales Service Provided: Engineers available to service
